Follow the steps in
Procedure 9 "Connecting multiple Local Carrier
Interface cards to the SDI card" (page 79)
Interface cards to the SDI card.
Procedure 9
Connecting multiple Local Carrier Interface cards to the SDI card
Step
Action
1
To connect a single NT7R51 Local Carrier Interface card to the
QPC 841 or other SDI cards:
Route the DB-9 female P2 connector of the NT7R67DA
cable assembly of the Local Carrier Interface card #1 to an
available SDI port on an SDI card.
Plug the DB-9 male connector of the NT8D93AJ XSDI I/O
cable into the DB-9 female SDI connector on the I/O panel.
Plug the DB-25 male connector of the NT8D93AJ XSDI I/O
cable into the DB-25 female connector on the NT7R66AA SDI
Cable Kit.
Plug the DB-9 male connector of the NT7R66AA SDI Cable
Kit into the DB-9 female connector into the NT7R67DA cable
P2 connector.
2
To connect other SDI cards:
Route and install the DB-9 female P2 connector of the
NT7R67DA cable assembly of the Local Carrier Interface
card #1 to an available SDI port on an SDI card.
Plug the DB-25 male connector of the NT7R66AA SDI Cable
Kit to connect the DB-25 female SDI connector at the I/O
panel. (The DB-25F/DB-25F adapter is not used).
Plug the DB-9 male connector on the NT7R66AA SDI Cable
Kit into the P2 connector on the NT7R67DA cable.
3
Secure cables with tie-wraps as appropriate.
To test the MMI and Host SDI login, refer to
"Host SDI mode" (page 121)
Note:
For additional information about types of SDI cards, their SDI
ports, and special cables required to connect these ports, refer to Circuit
Card Reference (NN43001-311) ().
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Local equipment installation 79
to connect multiple Local Carrier
--End--
"MMI mode" (page 120)
for login instructions.
