Nortel Communication Server 100 Manual page 4

4
Unpacking and inspection 57
Taking inventory 57
Routing carrier links to the Carrier Remote IPE site 58
Selecting the Local Carrier Interface card slot 58
Selecting the I/O Panel connector cutouts to install the Carrier I/O panel
Carrier Remote IPE connection record label 62
Local equipment installation 63
Installing and verifying system operation 64
Installing the Local Carrier Interface card 64
Installing the Local Carrier Interface cable assemblies 69
Installing SDI and local MMI terminal cables 72
Connecting the system monitor cables 80
Connecting the carrier link to the local system 84
Carrier Remote IPE column installation 86
Installing the Carrier Remote IPE column 86
Installing cards into the Remote IPE module 86
Installing the backplane cable assemblies 91
Installing system monitor cables 94
Installing remote MMI terminal cables 95
Connecting the carrier link to the Remote IPE module 96
Carrier Remote IPE cabinet installation 98
Installing the Carrier Remote IPE cabinet 99
Removing the fiber I/O bracket assembly 102
Installing the NT7R94AA Remote Cabinet Cable Assembly 103
Installing cards into the Carrier Remote IPE cabinet 104
Connecting carrier links to the Carrier Remote IPE cabinet 106
Connecting remote MMI terminal and subscriber loop cables 108
Connecting the attendant to the Carrier Remote IPE cabinet 112
Connecting the PFTU to the Carrier Remote IPE cabinet 113
Configuring the Carrier Remote IPE 114
Configuring the carrier interface cards 115
Configuring the remote MMI terminal port 120
Configuring the carriers 122
Verifying carrier link connections at the remote site 128
Carrier Remote IPE acceptance testing
Contents 133
Introduction 133
Overview 133
Checking the system 134
Setting up test conditions 135
Performing acceptance testing 135
Voice calls 136
assemblies 60
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
133
