Carrier remote ipe fundamentals
Table of Contents

Advertisement

Alarm Enabled: YES Self Clearing Enabled: YES
Sparing Enabled/Disabled: Enabled
All Link Maps Normal
Alarm Level 1 Threshold Value E-6 Threshold Duration (in seconds) 1
Alarm Level 2 Threshold Value E-5 Threshold Duration (in seconds) 1
Alarm Level 3 Threshold Value E-4 Threshold Duration (in seconds) 1
Frame Slip Alarm Level Threshold 100 Threshold Duration (in hours) 2
Current DIP Switch S1 Settings (s1-s8) OFF OFF ON ON OFF ON ON
OFF
Current DIP Switch S11 Settings (s1-s8) OFF OFF OFF ON ON OFF OFF
OFF
Note:
When the D C command is executed for the Carrier Remote IPE
cabinet at the remote site, it displays "XSM Emulation Active".
Parameter values explanation:
Alarm Enabled—Alarm monitoring and logging is enabled. CRI
messages are enabled.
Self Clearing Enabled—The alarm indicators (LED and external contact
closure) will automatically clear when the operational alarm level is
cleared.
Sparing Enabled/Disabled—Carrier 2 is enabled or disabled as a spare
carrier.
All Link Maps are Normal—No link has been spared. This is always the
case when carrier 2 is configured as a primary carrier link.
Alarm Threshold—Number of bipolar violations. E-6 represents 10
error in 1 million bits, E-5 represents 10
E-4 represents 10
Threshold duration—Carrier signal monitoring duration (1 second
to 3600 seconds) to detect bit error rate (CRC and BIPV) exceeding
threshold. The error counter is updated every second for the length of the
threshold duration.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Configuring the Carrier Remote IPE 131
–5
–4
or 1 error in 10,000 bits.
or 1 error in 100,000 bits, and
–6
or 1
