66 Equipment installation and configuration
Table 10
Local Carrier Interface standard (default) switch settings (cont'd.)
Figure 9 "Local Carrier Interface card DIP-switch positions and function"
(page 67)
through SW11, and their functions.
Switch 1
SW2 OFF ON
SW3 ON OFF
SW4 ON ON
SW5 OFF ON
SW6 ON OFF
SW7 ON ON
SW8 OFF ON
SW9 ON OFF
SW10 ON ON
shows the Local Carrier Interface card DIP switches, SW1
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Switch positions
2 3 4
OFF ON
ON ON
OFF OFF
OFF ON
ON ON
OFF OFF
OFF ON
ON ON
OFF OFF
5 6 7
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
- - -
8
-
-
-
-
-
-
-
-
-
