122 Equipment installation and configuration
For the MMI port at the Remote Carrier Interface card to be able to
communicate over the SDI port connected to the Local Carrier Interface
card, the interface characteristics must be the same:
•
Speed: 2400 bps or 1200 bps (Set by SW1 position 1)
•
Character width: 7 bits
•
Parity bit: mark
•
Stop bit: 1
In this mode, the remote TTY or terminal becomes a local system TTY that
can access overlays and perform system configuration, maintenance, and
diagnostics, which are the same functions performed by the local system
TTY.
To log into the host for SDI operation, first log in using the MMI terminal in
the MMI mode, then log into the terminal as host:
The Host SDI mode is accessed from the MMI mode by entering HOST
at the terminal or TTY. In this mode, the entire local system can be
configured and maintained. shows that, for example, LD 45 can be
activated to perform loopback testing.
To exit this mode, enter
@@@
Configuring the carriers
To configure the Carrier Remote IPE using the MMI terminal, you must
logon, enter the password, and use appropriate MMI commands.
Note:
letters can be used). The exception is the password, which must always
be entered in upper case.
Default factory carrier configuration
CRI>L
CRI::>
Enter Password > M1LINK
CRI::> HO
Enter Password > HOST
The commands are not case sensitive (upper or lower case
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Login command
Prompt after logging in
Type in the password.
To access the Host SDI mode
Enter the password HOST
