52 Equipment installation and configuration
IPE product description" (page 11)
numbers and their description.
2.
Identify empty network card slots. Refer to
supporting Local Carrier Interface cards" (page
3.
Configure the NT7R51 Local Carrier Interface card DIP-switches to set
the Local Carrier Interface card address and other parameters. Refer
to:
—
—
4.
Install the NT7R51 Local Carrier Interface card into a network card
slot. Refer
system options.
5.
Install the NT7R51 Local Carrier Interface card faceplate connector
assemblies. Refer to:
—
—
—
—
—
6.
Install the system monitor, local MMI terminal, and carrier link cables to
the carrier and maintenance panel assembly connectors. Refer to:
—
—
—
—
—
—
Figure 9 "Local Carrier Interface card DIP-switch positions and
function" (page 67) for switch settings.
Table 11 "NT7R51 Local Carrier Interface card maintenance
daisy-chain address" (page
to"Installing the Local Carrier Interface card" (page 64)
"Installing the Local Carrier Interface cable assemblies" (page 69)
"Connection diagrams and external connectors pin assignment"
(page 197)
Figure 26 "Single LCI connection diagram (local site connections)"
(page 198)
Figure 27 "Multiple LCIs connection diagram (local site daisy-chain
connection)" (page 199)
Figure 10 "Local Carrier Interface card faceplate cable connections
in Meridian 1 PBX 61C" (page 70)
"Installing SDI and local MMI terminal cables" (page 72)
"Connection diagrams and external connectors pin assignment"
(page 197)
Figure 30 "Local site system monitor connection diagram (single
and multiple LCI configuration)" (page 202)
"Connecting the carrier link to the local system" (page 84)
Figure 11 "System monitor, local MMI terminal, and carrier links
cable connections" (page 73)
"Connection diagrams and external connectors pin assignment"
(page 197) for connector pin assignments
