Maint. I/O Panel Connector Position – Enter the number of the selected
connector cutout on the I/O panel where the Maintenance Panel Assembly
is installed, for example J26.
Maint. Daisy-chain – Enter the appropriate information for P2 and P3
connectors of the NT7R67DA Local External Maintenance Cable Assembly
to identify what they are connected to. They can be connected as follows
(refer to
(page
P3 can be connected to the; MMI terminal or to P2 of SUPCxxx. P2 can
be connected to the; Host SDI port x, or P3 of SUPCxxx. where xxx in
SUPCxxx is the superloop number of the Local Carrier Interface card in
the daisy-chain.
Sys. Mon. Daisy-chain – Enter the appropriate information for J5 and
J6 modular jacks to identify what they are connected to. They can be
connected as follows (refer to
the local site and the Carrier Remote IPE" (page
J5 can be connected to; J6 of Master Sys. Mon. or to the next slave
system monitor in the direction of the master system monitor, or to the
next LCI SUPCxxx J6 in the direction of the master system monitor.
J6 can be connected to; J5 of the next system monitor in the direction
away from the master system monitor, or to J5 of the next LCI SUPCxxx
in the direction away from the master system monitor, where xxx in
SUPCxxx is the superloop number of the Local Carrier Interface card in
the daisy-chain.
Telco Circuit ID – Enter the telco circuit ID number for each carrier link
coming from the telco demarcation point.
For a collocated installation, where telco network is not used, specify the
cable pairs used for each carrier link.
Local equipment installation
To complete the installation of the T1 or E1 carrier interface that links the
system to the Carrier Remote IPE equipment:
•
install and verify the operation of the system, if not already installed
and operating correctly
•
identify the network card slot and install the Local Carrier Interface card
in the system
•
install the faceplate cables
•
connect the cable to the SDI, the system monitor, and the TTY ports
•
connect the carrier link to the I/O panel assembly
Figure 12 "Daisy-chaining multiple Local Carrier Interface cards"
80)):
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Local equipment installation 63
Figure 13 "System monitor connections at
84)):
