Refer to "Verifying carrier link connections at the remote site"
(page 128).
Note: Compare carrier circuit ID numbers of carrier links at
the local site (that were recorded during the installation of the
carrier links at the local site) with the carrier circuit ID numbers
of the carrier links at the remote site. Make sure they match
so that the circuit ID of carrier 0 at the local site matches with
circuit ID of carrier 0 at the remote site. Repeat this matching
for carrier 1 and carrier 2. This eliminates the mismatched
connection of carrier links, which causes time slot connection
problems indicated by no talk-path or cross-talk. To avoid
this problem, refer to
remote site" (page
3 Plug the carrier link 8-pin modular plug into the corresponding
NT7R59AA Carrier Panel and the NT7R60AA Carrier/Alarm
Panel assemblies 8-pin modular jack for each carrier.
4 If an E1 coaxial carrier link is terminated with BNC connectors,
use one NT7R67EA Coaxial Interface Adapter cable to connect
each 8-pin modular jack on the NT7R59AA Carrier Panel and
NT7R60AA Carrier/Alarm Panel assemblies to BNC carrier link
connectors.
5 Identify BNC connectors on each NT7R67EA Coaxial Interface
Adapter cable that corresponds to the appropriate carrier (carrier
0, carrier 1, and carrier 2) at the NT7R57AA Carrier Panel
Assembly 8-pin jack.
6 Connect each NT7R67EA Coaxial Interface Adapter BNC
connector to the appropriate BNC connector on the carrier link.
Note: These carrier link connections will be verified at the
end of hardware installation by executing appropriate MMI
commands on the MMI terminal. Refer to
connections at the remote site" (page
7 Secure the carrier link cables with tie-wraps at the exit from the
cabinet as appropriate.
Figure 18 "Carrier cable routing for the Carrier Remote IPE cabinet"
(page 108) shows the Carrier Remote IPE cabinet and the carrier cable
connecting carrier links to the cabinet.
