Remove the bracket.
Installing the NT7R94AA Remote Cabinet Cable Assembly
The NT7R94AA consists of the NT7R62AA Bracket, the NT7R68CA
Remote Carrier/Alarm Cable Assembly, and the NT7R68DA Remote
Maintenance Cable Assembly. These components are pre-assembled in
the factory to become the NT7R94AA Remote Cabinet Cable Assembly.
To install the NT7R94AA Remote Cabinet Cable Assembly into the
cabinet, follow the steps in
Remote Cabinet Cable Assembly" (page
Procedure 21
Installing the NT7R94AA Remote Cabinet Cable Assembly
Step Action
1 Align the two bracket holes with the two hinge tabs as shown
in Figure 17 "Carrier cable routing for the Carrier Remote IPE
cabinet" (page
2 Swing the front of the assembly by 45 degrees to the left with
respect to the hinge tabs.
3 Slide the entire assembly backwards and insert the hinge tabs
into the two holes on the bracket.
4 Move the front of the assembly by 45 degrees to the right to be
at the right angle to the backplane and install the retaining screw.
5 Plug the DB-15 male P1 connector at the common end of the
NT7R68CA cable assembly into the P3 (auxiliary) DB-15 female
connector located on the backplane.
6 Plug the DB-9 male P1connector at the common end of the
NT7R68DA cable assembly into the P2 (TTY) DB-9 female
connector located on the backplane.
Figure 17 "Carrier cable routing for the Carrier Remote IPE cabinet" (page
104) shows an installed and connected Remote Cabinet Cable Assembly.
The cables are connected to P2 and P3 located on the cabinet backplane
to provide connections to carrier links, the SDI/MMI terminal or TTY, the
PFTU, and the customer external alarms (alarms 1 and alarm 2 only).
