126 Equipment installation and configuration
To configure the carrier alarm thresholds. Defaults threshold values
are set in the factory and should not be changed unless there is a good
reason for doing so:
Note:
longer than 10 seconds to allow fast recovery of a faulty carrier when
the bit error rate improves. For example, if the duration is set to one
hour, a faulty carrier that starts operating correctly will wait one 1 hour
before the alarm condition is cleared and the carrier becomes available
for traffic again.
Parameter values explanation:
Equipped carrier 1 (Yes or No) Y
Equipped carrier 2 (Yes or No) Y
Enable #2 for Spare (Yes or No) Y
Enable self clearing Alarms
(Yes or No) Y
CRI:: >
CRI::> S A
Alarm 1 Threshold: Current value E-6 New value E-6
Threshold Duration (in seconds) Min –1 Max – 3600 Current value 1
Alarm 2 Threshold: Current value E-5 New value E-5
Threshold Duration (in seconds) Min – 1 Max – 2148 Current value 1
Alarm 3 Threshold: Current value E-4 New value E-4
Threshold Duration (in seconds) Min – 1 Max – 218 Current value 1
Frame Slip Threshold (Min – 1 Max – 255) Current Value 255
Frame Slip Threshold Duration (in Hours) Min – 1 Max – 24 Current Value 1
Threshold Duration parameter for BER thresholds should not be
Alarm 0 – No alarm, the carrier is operating without bit errors and without
excessive out of frame. If carrier was previously spared it is automatically
unspared.
Alarm 1 – The alarm indicates a low bit error rate (BER maintenance
threshold). The transmission continues without trying to spare this link.
Carrier maintenance should be scheduled. The alarm LED comes ON.
Nortel Communication Server 1000
Carrier Remote IPE Fundamentals
NN43021-555 04.01 4 June 2010
Copyright © 2007-2010 Nortel Networks. All Rights Reserved.
Enable carrier 1.
To enable carrier 2
Defines carrier 2 as spare
To enable/disable alarm clearing
Prompt requesting an MMI
command
To set carrier alarm parameters
