2.1 Product specifications

Description
Power input
Power output
Environment
condition
Mechanical
data
Protection
functions
202202 (V1.0)

2 Product overview

Table 2-1 Product specifications
Input voltage 380–480VAC 3PH ±10%, -15%<1min; Rated voltage: 380V
(V) 520–690VAC 3PH ±10%, -15%<1min; Rated voltage: 690V
Input current
See 2.3 Product ratings.
(A)
Input
frequency 50Hz or 60Hz; Allowed range: 47–63Hz
(Hz)
Output
Input voltage * 1.35
voltage (V)
Output
See 2.3 Product ratings.
current (A)
Output power
See 2.3 Product ratings.
(kW)
Working -10°C – +50°C; Derating is required when the ambient
temperature temperature exceeds 40°C.
Relative
5%–95%, no condensation
humidity
Installation Below 1000m (Derating is required when the altitude exceeds
altitude 1000m. Derate by 1% for every increase of 100m.)
Anti-vibration
Compliant with 3M4 vibration level in GB/T4798.3
performance
For the module: IP00
IP rating
For the cabinet: IP20 (Optional: IP23 and IP42)
Safety
Compliant with EN 61800-5-1
performance
Cooling
Forced air cooling
method
Including functions of protection against short circuit,
Protection
overcurrent, overload, overvoltage, undervoltage,
functions
overtemperature, and phase loss
