appear for SENSOR two. If both sensors are in self-test in the example above, then as the display
toggles between sensor one and two, the status line will remain indicating SELF TEST for both
sensor display updates.
Once the unit reaches full scale the SEC3120 automatically returns to normal and the SELF TEST
status will be removed from the display for that sensor.

INFO Menu Contents

12.
Using the UP and DOWN magnetic switches move the cursor to the desired field.
EJECT MEMORY CARD
ABORT WARMUP
* INFO
MAIN MENU
* UNIT INFO
SENSOR INFO
PREVIOUS MENU
UNIT INFO
* SENSOR INFO
PREVIOUS MENU
UNIT INFO
SENSOR INFO
* PREVIOUS MENU

Hide Low Gas

13.
The Hide function allows the operator to not display the gas reading (will always show 0) until the Low
Alarm threshold is exceeded. All outputs will function as normal when the Hide mode selected is YES.
* HIDE LOW GAS
SELF TEST
SET DATE TIME
PREVIOUS MENU
Operator Manual
SEC3120 Digital Transmitter
Entering the INFO menu will display the initial Info Menu
Selecting Enter at 'UNIT INFO' displays the information
for the SEC3120 Display, Dual Head Transmitter.
SEC3120 TRANSMITTER
VER: X.YY.RRRR
UNIT SN: 000035641
-ENT- TO EXIT
Selecting Enter
information for both of the sensors.
SENSOR INFO DISPLAY
IN: 003 SECONDS
PRESS
–ENT- TO EXIT
-S1 DDD-
TYP: XXX
FW: XX.X
SN: XXXXX
Select PREVIOUS MENU to go back to the initial menu
screen.
By selecting ENTER at HIDE LOW GAS, the operator can
choose to hide or not hide gas levels below the low
threshold. The following screen will appear:
Page 31 of 40
Sensor Electronics Corporation
'VER' is the SEC3120 software version
number.
'UNIT SN' is the SEC3120 unit serial
number.
at SENSOR INFO displays the
'003' counts down to '000' seconds
'DDD' – Device ID for sensor 1
-S2 EEE
'EEE' – Device ID for sensor 2
YYY
YY.Y TYP: Sensor type
YYYYY
(00 is a SEC3000, 32 is SEC
Millennium)
FW: Version of sensor software.
SN: Sensor serial number.
P/N 1580281
Rev 10, 20150707
