- Page 1 SEC 3000 Gas Detector Instruction and Operation Manual Sensor Electronics Corporation 5500 Lincoln Drive Minneapolis, Minnesota 55436 USA (952) 938-9486 Fax (952) 938-9617 Email sensor@minn.net Part Number 75-3000 Version 091404-001...
- Page 2 Sensor Electronics Corporation including but not limited to, the fitness for a particular purpose. In no event shall Sensor Electronics Corporation be liable for direct, incidental, or consequential loss or damage of any kind connected with the use of it's products or failure to function or operate properly.
-
Page 3: Table Of Contents
Table of Contents SPECIFICATIONS GENERAL DESCRIPTION III. OPERATION Installation and Startup IV. CALIBRATION MAINTENANCE VI. PARTS LIST VII. DRAWING SECTION... -
Page 4: Specifications
Phosphine Silane Formaldehyde Please note that this list is not all-inclusive. The SEC 3000 sensors can be calibrated for other toxic gases provided a calibration gas is available. For more please contact Sensor Electronics Corporation. Model Number: SEC3000 Detection Method: Electrochemical or Galvanic... -
Page 5: General Description
VDC (DC Voltage) SEC 3000 The SEC 3000 toxic gas detector is a microprocessor based intelligent gas detector that continuously monitors toxic gases and vapors ideally suited for use in harsh environments. The SEC 3000 is a stand-alone device providing a continuous 4 to 20 mA output. -
Page 6: Operation Installation And Startup
The first step in the installation process is to establish a mounting location for the SEC 3000. Select a location that is typical of the atmosphere to be monitored or close to the anticipated source of a dangerous gas. - Page 7 The detector continuously checks for system faults or initiation of calibration and automatically changes to the appropriate mode. The 4 to 20 mA output of the SEC 3000 is a non-isolated current source. Current Output and Corresponding Status Current Output Status.
-
Page 8: Calibration
The electronics will automatically adjust the sensor’s signal to the new zero reference level. During the zero calibration routine, the current output of the SEC 3000 will briefly go to 2.2 mA. Although this can be accomplished manually, installation of a switch (contact closure) can accomplish the zeroing procedure. -
Page 9: Maintenance
V. MAINTENANCE The SEC 3000 does not normally require routine maintenance other than calibration. The only consumable item on the SEC 3000 is the sensing element. The toxic gas sensing element will typically last for 2 years of operation. -
Page 10: Parts List
VI. Parts List Part Number Description SEC 3000 PC Link software package Sensor Separation Kit 1421468 Cal Adapter 1421467 Splash Guard 1421467 Sample Draw Adapter... - Page 11 Cross Sensitivity Table Gas Sensor Hydride COCl Form. 0.05 0.05 0.005 0.002 0.001 0.02 0.01 0.01 0.001 0.005 0.001 0.001 0.00002 0.001 0.05 0.05 0.04 -0.1 -0.1 -0.3 0.05 -0.08 -0.1 0.01 0.15 -0.07 -0.1 -0.3 -2.5 -0.8 -0.01 Hydri -0.04 -0.1 -0.8...
-
Page 12: Drawing Section
VII. Drawing Section Figure # Title Figure 1 Wiring Diagram, SEC 3000 Figure 2 SEC Sensor Separation Kit... - Page 14 Part Number Construction Gas Type Range Units Wire/Cable Wire Length XXXX Range Value (4 Places) M: PPM 0: Wires Inches Length B: PPB 1: Cable S: Standard Length V: %Vol (24”) L: %LEL B2H6: 32 AsH3: 32 BCl3: 21 BF3: 23 Cl2: 11 ClF3: 23 CO: 16...
