Detailed Specifications & Technical Data
ENGLISH MEASUREMENT VERSION
AWM Specification:
EU Directive 2011/65/EU (ROHS II):
EU CE Mark:
EU Directive 2000/53/EC (ELV):
EU Directive 2002/95/EC (RoHS):
EU RoHS Compliance Date (mm/dd/yyyy):
EU Directive 2002/96/EC (WEEE):
EU Directive 2003/11/EC (BFR):
CA Prop 65 (CJ for Wire & Cable):
MII Order #39 (China RoHS):
Flame Test
UL Flame Test:
Plenum/Non-Plenum
Plenum (Y/N):
Electrical Characteristics (Overall)
Nom. Capacitance Conductor to Conductor:
Capacitance (pF/ft)
26
Nom. Capacitance Cond. to Other Conductor & Shield:
Capacitance (pF/ft)
50
Nom. Conductor DC Resistance:
DCR @ 20°C (Ohm/1000 ft)
4.8
Max. Operating Voltage - UL:
Voltage Description
600 V RMS AWM Style 2107
300 V RMS CL3
Max. Recommended Current:
Current
7 Amps per conductor @ 25°C
Put Ups and Colors:
Item # Putup
8618 060U500 500 FT
8618 0601000 1,000 FT
8618 060500 500 FT
8618 0605000 5,000 FT
Notes:
C = CRATE REEL PUT-UP.
Revision Number: 3 Revision Date: 08-03-2012
© 2013 Belden, Inc
All Rights Reserved.
Although Belden makes every reasonable effort to ensure their accuracy at the time of this publication, information and specifications
described herein are subject to error or omission and to change without notice, and the listing of such information and specifications does not
ensure product availability.
Belden provides the information and specifications herein on an "AS IS" basis, with no representations or warranties, whether express,
statutory or implied. In no event will Belden be liable for any damages (including consequential, indirect, incidental, special, punitive, or
exemplary damages) whatsoever, even if Belden has been advised of the possibility of such damages, whether in an action under contract,
negligence or any other theory, arising out of or in connection with the use, or inability to use, the information or specifications described herein.
8618 Multi-Conductor - Audio, Control and Instrumentation Cable
UL Style 20253 (600 V 80°C)
Yes
Yes
Yes
Yes
01/01/2004
Yes
Yes
Yes
Yes
UL1685 UL Loading
No
Ship Weight Color
31.500 LB CHROME
67.000 LB CHROME
33.000 LB CHROME
325.000 LB CHROME
Page 2 of 3
Notes Item Desc
3 #16 LDPE FS PVC
C 3 #16 LDPE FS PVC
C 3 #16 LDPE FS PVC
3 #16 LDPE FS PVC
04-30-2013
