SEC IREvolution™
Specifications
Model: Sensor Electronics Corporation
SEC 5000 IREvolution™ Infrared
Gas Detector
Available Gases:
Propane Propylene
Methane n-Butane
Gasoline Ethanol
Ethylene Methanol
Pentane Ammonia
Cyclopentane Jet A
Sulfur Hexafluoride (SF6)
Please note that this list is not all-inclusive. The SEC
IREvolution™ can be calibrated for most hydrocarbons, CO
NH , provided a calibration gas is available. For more
3
information please contact Sensor Electronics Corporation.
Detection Method: Diffusion. Compatible with Optional
Sample-Draw Accessories. (requires a minimum of 1 liter
per minute flow rate.)
Output (analog):
4-20 mA (Source type), HART
max. 1000 Ohm load at 24 VDC supply voltage (including
field wiring)
Response Time:
T50 < 10 seconds
T90 < 20 seconds
Construction:
316 stainless steel or anodized aluminum
Accuracy:
+/- 5% of value or 0.5% of full scale
Repeatability:
+/- 2% of value
Operating Temperature Rating:
-40˚ to +70˚C at 0 to 99% RH (non-condensing)
Operating Range:
18 to 32 VDC measured at the detector head
Power Consumption:
5 Watts Max
Current Draw: (at 24VDC)
Average: 210 mA Peak: 400 mA
U.S. Patent: 6,414,310
7,132,657
Installation Category: Cat. I, Pollution Degree 2
Weight: 3.25 lbs. (1.5 kg.)
12730 Creek View Avenue, Savage, MN 55378 U.S.A. • (800) 285-3651 • (952) 938-9486 • FAX: (952) 938-9617
Diflouromethane
Diesel
Isopropyl Alcohol
DF 2000
Green Earth
Isobutane
PFC Gases
Sensor Electronics Corporation
Email: sales@sensorelectronics.com
Sensor Electronics Corporation reserves the right to alter specifications without prior notice.
Dimensions: Length 4.75" Diameter 2.5"
Certification
CSA/NRTL Class 1, Div. 1, Groups A, B,C,D T5
IECEx Exdb IIC T5 Gb
Unit Status Chart
Current Output
4-20 mA
0.6 mA
0.8 mA
,
0.9 mA
2
0.7 mA
1.0 mA
1.2 mA
1.6 mA
2.0 mA
2.2 mA
4.0 mA
5.6 mA
8.0 mA
12 mA
16 mA
20 mA
20.1 – 23 mA Over range (>100%)
Other Products Available
Gas Detectors – Explosion proof
Gas Detectors – Non-explosion proof
Infrared Gas Detectors
Process Gas Analyzers
Portable Fire Suppression Systems:
Stationary Fire Suppression Systems
• website: www.sensorelectronics.com
Infrared Gas Detector
Status
Normal measuring mode
Unit Fault
Reference channel fault
Analytical channel fault
Unit warm up
Optics fault
Zero drift fault
Calibration fault
Unit spanning
Unit Zeroing
Zero gas level
10% LEL
25% LEL
50% LEL
75% LEL
100% LEL
