Earth
Ground
Stud 10-32
3/4" NPT
THREAD
Sensor Electronics Corporation
5500 Lincoln Drive
Minneapolis, MN 55436
Tel: (952) 938-9486
Fax: (952) 938-9617
sales@sensorelectronic.com
11
WHITE: Calibration/Data
RED: +24 VDC
BLACK: -24VDC (DC Common)
BLUE: 4 TO 20 mA Out
OutOUTPUT
6.5 inches
165mm
2.6 inches
66mm
WIRING DIAGRAM
MILLENIUM SENSOR
FIGURE 1
