SEC Millenium
Specifications
Model: Sensor Electronics Corporation
SEC MILLENIUM Infrared Carbon Dioxide Gas Detector
Range: 0-0.5% Volume 4900135000M12 (5,000 ppm)
0-1% Volume 49001300001V12 (10,000 ppm)
0-2% Volume 49001300002V12 (20,000 ppm)
0-5% Volume 49001300005V12 (50,000 ppm)
Alternate ranges are available.
Detection Method: Diffusion - Optional sample draw
(requires a minimum of 1 liter per minute flow rate.)
Output (analog):
4-20 mA (Source type),
max. 1000 Ohm load at 24 VDC supply voltage
Response Time:
T50 < 5 seconds
T90 < 10 seconds
Construction:
316 stainless steel.
Class 1, Division 1, Groups B, C and D
Accuracy:
+/- 3% 0 to 50% Full Scale
+/- 5% 51 to 100% Full Scale
Operating Temperature Rating:
-40˚ to +70˚C at 0 to 99% RH (non-condensing)
Operating Range:
18 to 32 VDC measured at the detector head
Power Consumption:
5 Watts Max
Max Current Draw: (at 24VDC)
Average: 210 mA Peak: 400 mA
Approvals: Class 1, Division 1, Groups B,C,D
Installation Category: Cat. I, Pollution Degree 2
Weight: 5 lbs. (2.3 kg.)
12730 Creek View Avenue, Savage, MN 55378 U.S.A. • (800) 285-3651 • (952) 938-9486 • FAX: (952) 938-9617
Sensor Electronics Corporation reserves the right to alter specifications without prior notice.
Sensor Electronics Corporation
Email: sales@sensorelectronic.com
CO
Unit Status Chart
Current Output
4-20 mA
0.0 mA
0.2 mA
0.4 mA
0.8 mA
1.0 mA
1.2 mA
1.6 mA
2.0 mA
2.2 mA
4.0 mA
5.6 mA
8.0 mA
12 mA
16 mA
20 mA
20.1 – 23 mA Over range (>100%)
Other Products Available
Gas Detectors – Explosion proof
Gas Detectors – Non-explosion proof
Infrared Gas Detectors
Process Gas Analyzers
Dual Gas Analyzers
Portable Fire Suppression Systems:
Stationary Fire Suppression Systems
• website: www.sensorelectronic.com
Gas Detector
2
Status
Normal measuring mode
Unit Fault
Reference channel fault
Analytical channel fault
Unit warm up
Optics fault
Zero drift fault
Calibration fault
Unit spanning
Unit Zeroing
Zero gas level
10% Full Scale
25% Full Scale
50% Full Scale
75% Full Scale
100% Full Scale
Dry Chemical
Halotron
Twin Agent
© 09/13
