Internal Holding
Register Register
Address Address
x = sensor number (1 - 8)
value in its specific gas units (2x37,38), divide these *register values by the gas factor.
2x09 42x10
2x10 42x11
2x11 42x12
2x12 42x13
2x13 42x14
2x14 42x15
2x15 42x16
2x16 42x17
2x17 42x18
2x18 42x19
2x19 42x20
2x20 42x21
2x21 42x22
2x22 42x23
2x23 42x24
2x24 42x25
2x25 42x26
2x26 42x27
2x27 42x28
2x28 42x29
2x29 42x30
2x30 42x31
2x31 42x32
2x32 42x33
2x33 42x34
2x34 42x35
2x35 42x36
2x36 42x37
2x37 42x38
2x38 42x39
**See Sensor Status Parameter Table 8
***See Sensor Error Code Parameter Table 9
****Value is an IEEE 754 32-bit Floating Point number represented in its associated gas
units (2X37, 38). Values are split into two 16-bit register words, high word followed by
low word.
*****See Alarm Configuration Parameter Table 10
Sensor Gas Name Example: ASCII text such as "Chlorine", "Oxygen ", etc..
Sensor Gas Units Example: ASCII text such as "PPM ", "%LEL", "%V/V", etc.
SEC 3120 16-bit Modbus Manual
For Version 1.2 and above
Function Code 03- Read Sensor Register Description
(Data bits and Parameter Specifics)
Network Address ID (1 – 254)
Network Zone ID (1 – 254)
Sensor Device Type Code
(1/11= toxic, 2/12 = oxygen, 32/33 = infrared combustible,
others t.b.d.)
**Sensor Status Code
***Sensor Error Code
Sensor Cell Test Warning Code (128 - to 255 t.b.d)
Sensor Serial Number
**** Sensor Current Gas Concentration high word
**** Sensor Current Gas Concentration low word
Sensor Low Alarm Set Point Password Register
****Sensor Low Alarm Set Point high word
****Sensor Low Alarm Set Point low word
Sensor Mid Alarm Set Point Password Register
****Sensor Mid Alarm Set Point high word
****Sensor Mid Alarm Set Point low word
Sensor High Alarm Set Point Password Register
****Sensor High Alarm Set Point high word
****Sensor High Alarm Set Point low word
Sensor Calibration Value Password Register
****Sensor Calibration Value high word
****Sensor Calibration Value low word
****Sensor Range Value high word
****Sensor Range Value low word
*****Sensor Alarm Configuration
Sensor Gas Name (ASCII first and second characters)
Sensor Gas Name (ASCII third and fourth characters)
Sensor Gas Name (ASCII fifth and sixth characters)
Sensor Gas Name (ASCII seventh and eighth characters)
Sensor Gas Units (ASCII first and second characters)
Sensor Gas Units (ASCII third and fourth characters)
Page 27 Of 46
December 2012
Sensor Electronics Corporation
P/N 1580282, Rev. 1, 20121228
