WIRING TERMINATION
The wiring diagram is for the input power to the SEC 3500 and RS485 Data Highway Connection.
Earth Ground Connection
(Ground Stud)
Enclosure Wall
SEC P/N: 1460014
Rev / ECO: A / 000209
TB1
1 2 3 4
Terminal Description:
1 2 AMP Circuit Breaker Power for SEC 3500 only
2 DC Common
3 LAN Y DATA A
4 LAN Y DATA B
5 LAN Y ISOLATED DC COMMON
6 LAN X DATA A
7 LAN X DATA B
8 LAN X ISOLATED DC COMMON
5 6 7 8
