Arrow Down
ALARM LOW
LATCH
* ACTIVE
EXIT
Selecting Enter will allow the operator to change the operation of the relay operation from Active HI to Active
LOW. HI activates the relay on a rising alarm level. LOW actives the relay when the alarm threshold falls
below the alarm set point. Once the correct operation is selected, use the Down arrow to advance to the
next menu item.
Arrow Down
ALARM LOW
LATCH
ACTIVE
* EXIT
Selecting Exit will advance to the next menu.
* LOW
MID
HI
This menu will allow the operator to select another relay to program. Or select Fault or Exit and the next
display will be:
FAULT
* EXIT
Selecting Enter on this display will put the SEC 3100 back into normal operation.
HI
