Full burst of everything per gas detection scan loop:
StatCast Burst of all gas
detector records and global
and zone status records are
sent out RS232.
Records 1 – 271 (ALL).
Relay Module
Outputs are Set
Completion
of One Gas
Detection
Loop Cycle
Sliding-Window Burst per gas detection scan loop:
StatCast Burst of Records
Size =
num_records_per_scan
(lastnum+1) through (lastnum+1+
num_records_per_scan). Lastnum
is incremented by Size.
Relay Module
Outputs are Set
Completion
of One Gas
Detection
Loop Cycle
Therefore, if the number of records (size) to be sent per gas detection scan loop is
50 for example, and there are 100 detectors on the bus, it would require two full gas
detector scans to output all gas level and status records.
