  • Page 1 Edition 09.2 ’ ’ MAILING ADDRESS PHONE E-MAIL UL. ODLEWNIKÓW 18 PL-44-100 GLIWICE POLAND +48-32 237-26-88 +48-32 231-81-19 OFFICE@SENSOR-ELECTRONIC.PL...

  • Page 2: General Description

    2– Operator’s Manual SensoData 5500 SensoData 5500 is a universal datalogger, which can be attached to the following transducers or modules: - anemometer transducer type SensoAnemo 5100 - temperature transducer type SensoThermo 5200 - transducer of pressure and humidity type SensoHygBar 5300...
  • Page 3 - range of wire-less comm. : 60m - operation temperature: -20…50 1) Only for version SensoData 5500 Bee 2) It is not recommended to place the dataloggert below -5 C due to reduction of dynamic range and contrast of the LCD and battery performance.
  • Page 4 SensoData 5500 A. SensoData 5500 MK thermal comfort meter The basic set of thermal comfort meter consists of the SensoData 5500 datalogger and the SensoTCMod 5507 measuring module. Adding to the above set of two SensoTCMod 5503 measuring modules enables the...
  • Page 5 „patch cable” (total length of all connection cables should not be bigger than 10m). The DIN rail clip enables to fasten the SensoData 5500 datalogger on the arm of the mini-tripod, which is delivered in the set of thermal comfort meter (see photo in the right).
  • Page 6 6– Operator’s Manual SensoData 5500 is measured very close to high temperature sources). Both sensors can be also protected against mechanical damage using openwork basket (4) made with wire circles. If such a protection isn't necessary it is possible to removed them from the shielding tube (3).
  • Page 7 <4s B. SensoData 5500 Anemometer The SensoData 5500 Anemo is a device for the air speed and temperature measurement. The device enables measurements of jet ventilation and effectiveness of the ventilation in rooms as well as measurements of flow of inside different devices.
  • Page 8 - accuracy: ±0.05 m/s ±5% and 0.4 ºC - automatic temperature compensation: < niż ±0.3%/K  Barometric pressure sensor (only for SensoData 5500 Anemo B) enables the measurement of the barometric pressure and the automatic correction of anemometer readings at changes of the barometric pressure.
  • Page 9 9– Operator’s Manual SensoData 5500 The version of SensoData 5500 Thermo+ enables to connect four temperature probe with the help of screw connector (without the correction factors). Extended version SensoData 5500 Thermo HB enables additionally barometric pressure measurement using the built-in...
  • Page 10 A. Selection the measuring module for SensoData 5500 MK thermal comfort meter. The SensoData 5500 datalogger can be connected at the same time 3 modules. Each module contains 2 or 3 measuring transducers, which are identified separately by the datalogger. Measuring set for simultaneous...

  • Page 11: I N D I C A T O R S O N T H E D I S P L Ay

    11– Operator’s Manual SensoData 5500 B. Selection external transducer for SensoData 5500 Anemo To select external transducer, that is connected to the RJ45 socket (connector C – see Chapter 1), should on the ‘CONFIG SELECTION’ screen, that appears after turning on the datalogger, choose e.g ‘ANEMO EXTMOD’ by pressing the vertical cursors and press ‘OK’...
  • Page 12 12– Operator’s Manual SensoData 5500 Turn on Menu Shortcut Menu Automatic recording or writing samples to memory in single mode (SIN) Turn off Start Start the measurement in single mode (SIN) Scroll up screens with the results Scroll down screens with results...
  • Page 13 9 9 . 7 % S e r i e s n o. 0 0 0 5 A. SensoData 5500 MK Thermal Comfort meter The screens with results are presented below.  Z H T H E R M A L C O M F O R T 2 3.
  • Page 14 14– Operator’s Manual SensoData 5500 H I G R O B A R O P b = 9 8 5 . 4 h P a R H = 6 4 . 6 00:08 Pb - barometric pressure RH - relative humidity ...
  • Page 15 15– Operator’s Manual SensoData 5500 For cold environment appears the following screens additionally:  C  C T H E R M A L C O M F O R T T H E R M A L C O M F O R T...
  • Page 16 C. SensoData 5500 Thermo-meter. Below are presented the screens with results for SensoData 5500 Thermo (left) and SensoData 5500 Thermo+ (on the right).
  • Page 17 17– Operator’s Manual SensoData 5500 In addition for SensoData 5500 Thermo HB is displayed screen with results (see below). H I G R O B A R O P b = 9 8 5 . 4 h P a R H = 6 4 . 6...
  • Page 18 18– Operator’s Manual SensoData 5500 increases at each entrance to the single mode. The serial number can be increased also by pressing the keys sequence: ‘Menu’ and ‘Rec’. At each of the measuring series is placed a header with the date and the input parameters.
  • Page 19 19– Operator’s Manual SensoData 5500  Recording configuration After pressing the ‘Rec’ key, appears the following screen with the recording parameters: Interval – specifies the time between samples Recording time – specifies the time since the start, after which you want to stop recording.
  • Page 20 - try to reassign COM port to a unused port number - click OK when finished. The device in the SensoData 5500 Bee version is equipped with a radio receiver that allows wireless communication with measuring modules (transducers). Modules (transducers) must be connected to the SensoBee 485 wire-less...

  • Page 21: Dewpoint Temperature

    21– Operator’s Manual SensoData 5500 - turn on the SensoBee 485 wire-less transmitter (switch on the side to the ‘Bee’ position), the blue led on top of the casing will blink - double press ‘Menu’ key on the keyboard - select ‘Wireless conn’ item and press ‘OK’ key - select enable mode by pressing the horizontal cursor - press ‘OK.’...
  • Page 22 22– Operator’s Manual SensoData 5500  Mean Radiant Temperature [              , where         max_    where t is globe temperature for globe diameter of 7.5cm ...

  • Page 23: Wind Chill Temperature

    23– Operator’s Manual SensoData 5500  Maximal Evaporation Rate [W/m   , where           30535               ...
  • Page 24 24– Operator’s Manual SensoData 5500 A. SensoBee wire-less transmitter The SensoBee transmitter contains an RF module for wire-less data transmission. The RF module operates under ZigBee (802.15.4) protocol accepted by ETSI/EC (Europe), FCC (U.S.A) and IC (Canada). The transducers are connected to the SensoBee wire-less transmitter by RJ45 socket B.
  • Page 25 25– Operator’s Manual SensoData 5500 B. PowerBank PowerBank is a high-performance external battery pack with latch for DIN rail. The latch allows for easy installation of the device on a tripod along with other parts of the measuring system. Includes a charging cable (USB to micro USB) and spiral power cable (USB-plug DC) with a length of 30-100 cm.
  • Page 26 26– Operator’s Manual SensoData 5500 C. Fold-out tripod Measurement system can be equipped with a fold-out tripod adapted to mount several measuring transducers with accessories. The tripod consists of the following parts presented in the photos below. The way of assembling of the tripod is shown in the photos below. Attention should be paid to the pipes D1 ... D3 turn in the order corresponding to the incisions, ie.
  • Page 27 The DIN rail-mounted grip enables to mount the devices equipped with latch for DIN rail, so as: SensoBee wire-less transmitter or SensoData 5500 datalogger. Manufacturer guarantees the correct operation of the devices. The guarantee period is 24 months, beginning from the date of sale.
