Main Menu - Sensor Electronics SEC Millenium Series Instruction And Operation Manual

5.1

Main Menu

1) Safe Power Off - Selecting this item is crucial for insuring that data collected, settings
made, etc. are permanently stored. Data is stored in internal volatile RAM, and
occasionally stored into permanent storage after varying periods of time. To insure
that there is no data loss due to this uncertainty, selecting this option causes this data
to be permanently saved, the panel is prepared for a valid power-of condition, and
will not display the main page until the operator is ready for normal operation, thus
insuring the communication busses are essential down. See section 5.2.
2) About SEC...- Pressing this touch item pops up the information box, describing the
contact information for Sensor Electronics Corporation, as well as the firmware
version of the SEC 3500, and provides a shortcut to logging into the panel. See
section 5.3.
3) Login/Logout- Pressing this allows the user to Login to another account, or logout of
the current account. For higher level users, this allows passwords to be changed as
well. See section 5.4.
4) Screen Selection- This is the primary selection used by operators for screen
navigation; it allows the operator to select a specific screen or function screen to go to.
See section 5.5.
5) Supervisor Menu- Notice that it is missing the surrounding box with white borders.
This indicates that it is inactive. When the operator is logged in as the supervisor or
higher user, this item will be fully active as the others and allow the supervisor user to
access other sub-menus for configuration.
6) Exit Menu- Pressing this should cause the menu to be removed from the screen
behind it.
Sensor Electronics Corporation
5500 Lincoln Drive
Minneapolis, Minnesota 55436
th
July 28 , 2007
Page 38 of 49
952-938-9486
SEC 3500 OI
Basic Operator's
Manual
Version 2.1.0095
