Function Code 16 - Write Multiple Holding Registers
Description
Writes a set of values into one or more sequential holding registers (4x
references). Modbus does NOT allow a broadcast mode with this function code.

Table 12: Function Code 16 Multiple Write Holding Registers

Internal Holding
Register Register
Address Address
x = sensor number, or
0 to apply to all sensors.
2x03 42x04
2x04 42x05
2x05 42x06
2x06 42x07
2x10 42x11
2x18 42x19
2x19 42x20
2x20 42x21
2x21 42x22
2x22 42x23
2x23 42x24
2x24 42x25
2x25 42x26
2x26 42x27
2x27 42x28
2x28 42x29
2x29 42x30
2x39 42x40
SEC 3120 16-bit Modbus Manual
For Version 1.2 and above
Function Code 16- Write Multiple Sensor Registers
(Data bits and Parameter Specifics)
*Scaled Integer Sensor Alarm Low Set Point.
4000 Hex must be added as a password to write value.
*Scaled Integer Sensor Alarm Mid Set Point.
4000 Hex must be added as a password to write value.
*Scaled Integer Sensor Alarm High Set Point.
4000 Hex must be added as a password to write value.
*Scaled Integer Sensor Calibration Value.
4000 Hex must be added as a password to write value.
***Sensor Zone ID.
4000 Hex must be added as a password to write value.
Sensor Low Set Point Enable Register.
This register must be written to first with 4259 Hex as a
password.
**Sensor Low Alarm Set Point Float high word.
**Sensor Low Alarm Set Point Float low word.
Sensor Low Alarm Set Point Enable Register.
This register must be written to first with 4259 Hex as a
password.
**Sensor Alarm Mid Set Point Float high word.
**Sensor Alarm Mid Set Point Float low word.
Sensor Alarm High Set Point Enable Register.
This register must be written to first with 4259 Hex as a
password.
**Sensor Alarm High Set Point Float high word.
**Sensor Alarm High Set Point Float low word.
Sensor Calibration Value Enable Register.
This register must be written to first with 4259 Hex as a
password.
**Sensor Calibration Value Float high word.
**Sensor Calibration Value Float low word.
***Start Sensor Self Test Operation (00FF Hex Start, 0
stop)
4000 Hex must be added as a password to write value.
