Table 11: Function Code 06 Preset Holding Register

Internal Holding
Register Register
Address Address
x = sensor number, or
0 to apply to all sensors.
2x03 42x04
2x04 42x05
2x05 42x06
2x06 42x07
2x10 42x11
2x39 42x40
*The real value must be multiplied by the Gas Factor (2x08).
i.e. 2.12 ppm to set low set point register: scaled low set point = 2.12 X 10 (from 2x08) =
212 (00D4 Hex). When the password is added (4000 Hex) the complete value needed to
write the register and change the low set point then is 40D4 Hex.
** Zone ID (2010/42012) and Self Test (2039/42040) may be written to in region zero
(apply to all sensors) for a 3120 with two or more sensors attached, when the sensor role
is either "Unique" or "Identical" modes, but NOT when in "Single" sensor role- an
exception message will be generated and sent back to the master in place of a message
echo. If sensor role is "Identical", values must also be identical!
Internal Holding
Register Register
Address Address
2911 42912
2912 42913
2913 42914
2914 42915
2915 42916
2916 42917
2917 42918
SEC 3120 16-bit Modbus Manual
For Version 1.2 and above
Function Code 06- Preset Sensor Register Description
(Data bits and Parameter Specifics)
*Scaled Integer Sensor Alarm Low Set Point.
4000 Hex must be added as a password to write value.
*Scaled Integer Sensor Alarm Mid Set Point.
4000 Hex must be added as a password to write value.
*Scaled Integer Sensor Alarm High Set Point.
4000 Hex must be added as a password to write value.
*Scaled Integer Sensor Calibration Value.
4000 Hex must be added as a password to write value.
**Sensor Zone ID.
4000 Hex must be added as a password to write value.
**Start Sensor Self Test Operation (00FF Hex Start, 0 stop)
4000 Hex must be added as a password to write value.
Function Code 06- Preset Unit Register Description
(Data bits and Parameter Specifics)
New 3120 Unit Clock Month Value.
4000 Hex must be added as a password to write value.
New 3120 Unit Clock Day Value.
4000 Hex must be added as a password to write value.
New 3120 Unit Clock Year Value.
4000 Hex must be added as a password to write value.
New 3120 Unit Clock Hours Value.
4000 Hex must be added as a password to write value.
New 3120 Unit Clock Minutes Value.
4000 Hex must be added as a password to write value.
New 3120 Unit Clock Seconds Value.
4000 Hex must be added as a password to write value.
Set New 3120 Unit Clock NOW (00FF Hex set, 0 clear).
4000 Hex must be added as a password to write value.
