7.6

Manually Forcing Relay Coil States

From the Relay Assignment Screen, you can force individual coils on and off to test
connections, behavior, etc. First you must press the "Enable" button below to cause the
state to change as indicated ("On" means energized, "Off" means de-energized):
When the "Enable" button is green as shown here:
not enabled. Press it and it will turn red
"Enabled" indicating that whatever state t
state that the SEC 3500 OI panel is now forcing for this coil on this Relay Module. Coils
can be forced regardless of whether or not they have been assigned. You can also choose
to change the state of the coil to "On" or "Off" before enabling the force. Insure that
before you leave this screen, you disable the coil forcing, or your Relay Module
obviously will not behave as you expect! When the coil is set to be forced to "Off" it
appears in green
the text "On".
Sensor Electronics Corporation
5500 Lincoln Drive
Minneapolis, Minnesota 55436
th
September 29 , 2006
he "On"/"Off" button is showing, is now the
and in red when it is set to be forced on with
Page 43 of 66
952-938-9486
forcing the coil state is
(and the text will
Supervisor Operator's
Version 2.1.0095
change to
SEC 3500 OI
Manual
