Table 9: Sensor Error Code Parameter Table

Error Code (Hex)
0000
0001
0002
0003
0004
0005
0006
0007
0008
0009
000A
000B
000C
000D
000E
000F
0010
0011
0012
0013
0014
0015
0016
0017
0018
0019
001A
001B - 00FF
SEC 3120 16-bit Modbus Manual
For Version 1.2 and above
No error, all is well and OK.
EEPROM Header Error.
EEPROM Checksum Error.
Sensor Never Zero Calibrated.
Sensor Never Span Calibrated.
Zero values out of spec.
4-20ma Calibration 1 error.
4-20ma Calibration 2 error.
Signal High Error.
4VDC Reference Low.
4VDC Reference High.
Balance Pot Max.
Balance Pot Min.
AGC Pot Max.
AGC Pot Min.
Span Pot Max.
Span Pot Min.
Sensor Never Hot Zero Calibrated.
Sensor Never Cool Zero Calibrated.
Unit Temperature > +85 degrees Celsius.
Unit Temperature < -35 degrees Celsius.
Insufficient Analytical Range.
No table downloaded.
Span calibration invalidated by new range or calibration value.
Span Pot overflow (not enough span pot range for temperature
adjustment or insufficient analog signal).
24VDC Supply Low.
24VDC Supply High.
t.b.d.
