Main Zone Summary Screen- Status Bar - Sensor Electronics SEC Millenium Series Instruction And Operation Manual

4.1.3 Main Zone Summary Screen- Status Bar

1) Screen Label & Navigation.
a) P ress to toggle between
M ain Zone Screen and
Bus Summary Screen.
2 ) Global Alarm Status Text- (As
previously described in 4.1.1).
Press th is to display Alar
3) Communications Currently Reading Bus.
4 ) SEC 3500 Clock Date and Tim
to enter the Clock chang
5) SEC Logo- Press to bring up the SEC Main Menu.
6 ) Current Operator Logged On to the SEC 3500 Panel
(Operator is default without a logon), and Tim
Aut o-Logoff.
Important Note: It is important to rea
remains constant for all of the main
st atus bars and status text. The only difference will be the screen name in the lower left
corner. If the screen name is followed by a navigation
the above screen), then it allows rapid navigation
Summary screen.
