SHOWN WITH SEC MILLENIUM SENSOR
Features
Applications
• Petrochemical Refineries
• Compost Facilities
• Semi-Conductor Industry
• Mining
• Pulp and Paper Mills
• Oil Rig Platforms
• Buildings
• Automotive Industry
• Engine Test Rooms
Operation / Description
The SEC 3100 provides interface capabilities for the SEC 3000 Gas Detector and SEC Millenium
Infrared Gas Detectors.
The SEC 3100 features:
• Back lighted LCD for Gas Level/Unit Parameter display
• Four (4) configurable Alarm/Fault Relays
• An isolated RS485 Modbus interface provides reliable communication in noisy environments and
eliminates "Ground Loop" problems.
• Three magnetic switches for local configuration and calibration
• Time stamped data logging using a removable non-volatile memory module. Module can be
removed from the unit to allow remote data downloading and data archiving.
An optional IS barrier allows "hot" sensor replacement in rated locations. This allows the user to install
pre-calibrated/pre-configured sensor boards without removing unit power while maintaining EX rating.
Removable circuit board stack and detachable connectors facilitate field-wiring installation.
• Explosion Proof
• Back lighted LCD Display
• Low Cost
• Plug and play toxic, oxygen and combustible gas sensors
• Self-Check system
• 4-20 mA output
• RS-485 Interface (Isolated)
• Alarm and fault relays
• Non-intrusive configuration
• Non-intrusive calibration
• Removable, non-volatile, time stamped data logging memory stick
• Optional IS barrier
• Digital communication link to SEC 3000 and SEC Millenium Gas Detectors
• Multi port housing for easy installation
Digital Gas Transmitter
• LNG & LPG Facilities
• Sewage Industry
• Water Treatment Plants
• Parking Garages
• Chemical Industry
• Nuclear Industry
• Fertilizer Industry
• Tunnels
• Medical Facilities
SEC 3100
© REV 3, 2/15
