4.8.3 Control Panel

4.8.3 Control Panel
1 1 Control Panel ) Control Panel- This display panel will remain in this location throughout all )
configuration screens that each of these control buttons will change to. Configuration
is not handled in this manual.
2) Info Box- Displays the last calibration date and the range of the sensor.
3) Calibrate- Enters the calibration process screens. Not handled by this manual.
4) Set Alarms - Enters the alarm threshold set point screen. Not handled by this manual.
5) Manual Control- Allows manual drive and control of 3100 relays and lamp test. Not
handled by this manual.
6) Set 3100 Clock - Allows setting this 3100 clock or all 3100 clocks on the bus.
