Electronics
Multi-Conductor, Foil Shield
NEC Type CMP (UL) c(UL) and CL3P
CATALOG NO. OF AWG COND.
NUMBER COND. SIZE STRAND
C3158
2 22 7/30 TC
C3159
4 22 7/30 TC
C3060
2 18 Solid BC
C3061
4 18 Solid BC
C3062
2 18 7/26 BC
C3064
3 18 7/26 BC
C3063
4 18 7/26 BC
C3065
6 18 7/26 BC
C3183
10 18 7/26 BC
C3184
12 18 7/26 BC
C3068
2 16 19/.0117 BC 0.009
*A – Capacitance between conductors
*B – Capacitance between one conductor and other conductors connected to shield
Color Code Chart
NO. OF
COND. COLOR
1
Black
2
White
3
Red
4
Green
5
Brown
6
Blue
7
Orange
8
Yellow
9
Violet
10
Gray
11
Pink
12
Tan
NOM. INSULATION NOM. JACKET
THICKNESS THICKNESS
INCHES mm INCHES mm INCHES
22 AWG CONDUCTORS
0.008 0.20 0.015 0.38 0.127
0.008 0.20 0.015 0.38 0.146
18 AWG CONDUCTORS
0.008 0.20 0.015 0.38 0.148
0.008 0.20 0.015 0.38 0.171
0.008 0.20 0.015 0.38 0.164
0.008 0.20 0.015 0.38 0.169
0.008 0.20 0.015 0.38 0.185
0.010 0.25 0.015 0.38 0.230
0.012 0.20 0.015 0.38 0.310
0.010 0.25 0.015 0.38 0.308
16 AWG CONDUCTORS
0.23 0.015 0.38 0.187
Communication & Control Cable, Multi-Conductor
Product Construction:
Conductor:
Insulation:
NOM. CAP.*
NOMINAL O.D. pF/ft
mm A B
Shield:
3.23 51.0 91.0
3.71 45.0 81.0
Jacket:
3.76 67.0 120.0
4.34 58.0 104.0
4.17 61.0 110.0
4.29 53.0 96.0
Applications:
4.70 53.0 96.0
5.84 48.0 86.0
7.87 47.0 84.0
7.82 52.5 94.6
Compliances:
4.75 75.0 134.0
Features:
Packaging:
• 22 thru 16 AWG fully annealed stranded
tinned or bare copper per ASTM B-3,
B-8 or B-33
• Premium-grade, coIor-coded Flexguard
PVC
• Color code: See chart below
• 100% Flexfoil ® aluminum/polyester foil
with 25% overlap, minimum
• Stranded tinned copper drain wire
• Flexguard ® PVC, natural
• Temperature range: 0°C to +75°C
• Sequential footage marked to facilitate
installation
• Includes ripcord
• Intercom systems
• Background music
• Audio systems
• Power-limited control circuits
• Suggested voltage rating: 150 volts
• NEC Article 725 (UL: 75°C, 150V)
• NEC Article 800 (UL: 75°C, 300V)
• Designed to meet NFPA 262 and CSA
FT-6 Steiner Tunnel Fire Tests for Plenum
Applications
• Flexible
• Easy to terminate
• Please contact Customer Service for
packaging and color options
®
28
