Main Menu and Sub Menus
EJECT MEMORY CARD
INFO
* MAIN MENU
Enter
* CALIBRATION
ALARM
RELAY
Down Arrow
CALIBRATION
* ALARM
RELAY
Down Arrow
CALIBRATION
ALARM
* RELAY
Down Arrow
* NETWORK
HIDE
Down Arrow
NETWORK
* HIDE
Down Arrow
* SELF TEST
DATE TIME
Down Menu
SELF TEST
* DATE TIME
Down Arrow
* 4 – 20 MA CAL
EXIT
Down Arrow
4 – 20 MA CAL
* EXIT
Calibration Menu
Used to calibrate
the gas sensor.
Alarm Menu
Used to set
alarm level set
points and
parameters.
Relay Menu
For setting
alarm relay
On & Off delay &
Energized states.
Network Menu
Used to set
Zone #, ID # and
NO
Select Online
Hide Menu
Hide is used to
NO
blank the
display up to
low alarm setting
Self Test Menu
Generates a
signal on the
display, RS485
& 4-20 mA
Date Time Menu
Sets the date
and time in the
real time clock.
4 – 20 MA CAL
Allows user to increase
or decrease 4.0 mA
current output, or adjust
20 mA current output
Exit back to normal
operation.
