I. SPECIFICATIONS
Model:
SEC 3000 Gas Detector
Model Number: SEC3000
Available gases:
Ammonia
Nitric Oxide
Bromine
Fluorine
Hydrogen Chloride
Hydrogen Sulfide
Arsine
Hydrogen Selenide
Formaldehyde
Please note that this list is not all-inclusive. The SEC 3000 sensors can be calibrated for other toxic gases
provided a calibration gas is available. For more please contact Sensor Electronics Corporation.
Detection Method: Electrochemical or Galvanic
Aspiration:
Diffusion
Optional Sample Draw (requires 1 liter per minute sample flow rate)
Output (Analog): 4-20 mA (Source type), max. 1000 Ohm load at 24 VDC supply voltage
Output (Digital) Interactive Interface Available On The Calibration (White) Wire
Response Time: Varies for type of sensing element
Construction: 316 Stainless Steel Explosion Proof
Accuracy: +/- 5%
Operating Temperature Rating:
-40 to +50C at 0 to 99% RH (non-condensing)
Operating Voltage:
8 to 32 VDC measured at the detector head
Power Consumption: 1 Watt Max.
Max. Current Draw: 40 mA (at 24 VDC)
Approvals:
Explosion Proof CSA c,us: Class I, Division 1, Groups B,C,D T6
IECEx CSA 13.00xx: Ex d IIB+H2 T4 Gb
Intrinsically Safe CSAc,us: Cl I, Division 1, Groups
IECEx CSA 13.00xx: Ex ia IIC T4 Ga
Installation Category: Cat. I, Pollution Degree 2
Doc#: 1460003, Rev A
Carbon Monoxide
Oxygen
Chlorine
Hydrogen Peroxide
Hydrogen Cyanide Hydrogen Fluoride
Nitrogen Dioxide
Diborane
Phosphine
ABCD
Operation Manual, SEC 3000 Electro-Chemical Gas Sensor
Hydrogen
Phosgene
Chlorine Dioxide
Ozone
Sulfur Dioxide
Germane
Silane
Vmax Imax
10.4V 148mA 1.2W 2.51uF 22.5uH
CD 16.4V 148mA 1.2W 2.51uF 22.5uH
D 26.3V 148mA 1.2W 2.51uF 22.5uH
Pmax Ci Li T-Code
T4
T4
T4
Page 4 of 13
