SEC IREvolution™
Specifications
Model: Sensor Electronics Corporation
SEC 5000 IREvolution™ Infrared
Ammonia Gas Detector
Part Numbers and Ranges:
Range
0-10% VOL
0-1000 PPM
0-2500 PPM
0-10,000 PPM
Please note that this list is not all-inclusive. The SEC
IREvolution™ can be calibrated for most hydrocarbons, CO
NH , provided a calibration gas is available. For more
3
information please contact Sensor Electronics Corporation.
Detection Method: Diffusion. Compatible with Optional
Sample-Draw Accessories. (requires a minimum of 1 liter
per minute flow rate.)
Output (analog):
4-20 mA (Source type), HART
max. 1000 Ohm load at 24 VDC supply voltage (including
field wiring)
Response Time:
T50 < 10 seconds
T90 < 20 seconds
Construction:
Anodized aluminum, 316 stainless steel
Accuracy:
+/- 5% of value or 0.5% of full scale
Repeatability:
+/- 2% of value
Operating Temperature Rating:
-40˚ to +70˚C at 0 to 99% RH (non-condensing)
Operating Range:
18 to 32 VDC measured at the detector head
Power Consumption:
5 Watts Max
Current Draw: (at 24VDC)
Average: 210 mA Peak: 400 mA
U.S. Patent: 6,414,310
7,132,657
Installation Category: Cat. I, Pollution Degree 2
12730 Creek View Avenue, Savage, MN 55378 U.S.A. • (800) 285-3651 • (952) 938-9486 • FAX: (952) 938-9617
Part Number
5100-013
5100-012
5100-011
5100-001
Sensor Electronics Corporation
Email: sales@sensorelectronics.com
Sensor Electronics Corporation reserves the right to alter specifications without prior notice.
Dimensions: Length 11" Diameter 2.75"
Length 5"
Certification
CSA/NRTL Class 1, Div. 1, Groups A, B,C,D T5
IECEx Class 1, Zone 1, Group IIC - Pending
Unit Status Chart
Current Output
4-20 mA
0.6 mA
,
2
0.8 mA
0.9 mA
0.7 mA
1.0 mA
1.2 mA
1.6 mA
2.0 mA
2.2 mA
4.0 mA
5.6 mA
8.0 mA
12 mA
16 mA
20 mA
20.1 – 23 mA Over range (>100%)
Other Products Available
Gas Detectors – Explosion proof
Gas Detectors – Non-explosion proof
Infrared Gas Detectors
Process Gas Analyzers
Portable Fire Suppression Systems:
Stationary Fire Suppression Systems
• website: www.sensorelectronics.com
Infrared Gas Detector
Diameter 2.75"
Status
Normal measuring mode
Unit Fault
Reference channel fault
Analytical channel fault
Unit warm up
Optics fault
Zero drift fault
Calibration fault
Unit spanning
Unit Zeroing
Zero gas level
10% LEL
25% LEL
50% LEL
75% LEL
100% LEL
Dual Gas Analyzers
Dry Chemical
Halotron
Twin Agent
Weight 3 lbs.
Weight 1.8 lbs.
© 03/16
