4 – 20 MA CAL Menu
* 4 – 20 MA CAL
EXIT
The 4 – 20 MA CAL Menu will allow the operator to increase or decrease the 4 to 20 mA output current at
4.0 mA and at 20 mA. Typically this menu is not often used in the field because the analog signals are set
at the factory.
Selecting Enter will display the following:
* SET 4 MA
SET 20 MA
DEFAULTS
EXIT
Selecting Enter will display the following:
* 4 MA PT: 0
ENT WHEN COMPLETE
Using the UP / DOWN arrows will increase (UP arrow) or decrease (DOWN arrow) the number. Increasing
the number will raise the 4.0 mA current output, lowering the number will decrease the 4.0 mA number.
Note the number can be set to a negative number (-2 etc). Once the correct current output is set, pass the
magnet over the ENTER Arrow and this will accept the new settings.
The display will be the following:
* SET 4 MA
SET 20 MA
DEFAULTS
EXIT
To adjust the full scale 20 mA current output arrow down and select ENTER:
SET 4 MA
* SET 20 MA
DEFAULTS
EXIT
Using the UP / DOWN arrows will increase (UP arrow) or decrease (DOWN arrow) the number. Increasing
the number will raise the 20.0 mA current output, lowering the number will decrease the 4.0 mA number.
Note the number can be set to a negative number (-2 etc). Once the correct current output is set, pass the
magnet over the ENTER Arrow and this will accept the new settings.
Arrow down to this display and select ENTER to clear all user set numbers. Both 4 MA and 20 MA will
return to 0
SET 4 MA
SET 20 MA
* DEFAULTS
EXIT
Arrow down and select Enter to return to the SEC 3100 to 4-20 MA CAL main menu..
SET 4 MA
SET 20 MA
DEFAULTS
* EXIT
