EJECT MEMORY CARD
ABORT WARMUP
INFO
* MAIN MENU
CALIBRATION
ALARM
RELAY
* NETWORK
Operator Manual
SEC3120 Digital Transmitter
From the Initial/Top menu screen, cursor down to the Main Menu
and select ENTER.
Move the cursor down to the NETWORK menu and select
ENTER.
* NETWORK ID MENU
MODBUS SETTINGS
PREVIOUS MENU
* FOR SENSOR: ONE/TWO *
ID
ZONE
PREVIOUS MENU
FOR SENSOR: ONE/TWO
* ID
ZONE
PREVIOUS MENU
Note: Be sure to assign the sensor an ID number not
shared by any other sensors in the HMI's network.
FOR SENSOR: ONE/TWO
ID
* ZONE
PREVIOUS MENU
FOR SENSOR: ONE
ID
ZONE
* PREVIOUS MENU
NETWORK ID MENU
MODBUS SETTINGS
* PREVIOUS MENU
* SAVE CHANGES
ABORT CHANGES
Page 22 of 40
Sensor Electronics Corporation
Select ENTER on NETWORK ID MENU.
If the ID mode (see Modbus settings
menu) is not set to 'Single' and Sensor
XXX
YYY
Role (see Modbus settings menu) is not
set to 'Single', then you may change the
ID and Zone number for either sensor
one or two by choosing the sensor
number.
SENSOR' item, and use the UP/DN
arrows to change between ONE and
TWO. Otherwise, if ID mode or Sensor
Role is set to 'Single' all changes will be
made with SENSOR ONE displayed.
To set the ID of each sensor move the
cursor to ID and select ENTER. The IDs
XXX *
of the sensors may be set in the range 1-
YYY
254, however they cannot be set to the
same value.
To set the Zone of each sensor move the
XXX
cursor to ZONE and select ENTER. The
YYY *
ZONE can be set in the range 1-254.
Scroll down and select ENTER on
13 PREVIOUS MENU to return to the
3
Network Menu Screen.
Scroll down to and select ENTER on PREVIOUS
MENU to return to the Main Menu.
ENTER on 'SAVE CHANGES' to return to the
Main Menu.
Select ENTER on
P/N 1580281
Rev 10, 20150707
