start on page 46 and end on 49. The default username is super and the default
password is also super (this can be changed later, follow page 56 for this in the manual).
6) Once the supervisor has logged in, press the "Supervisor Menu" button.
7) This will bring up a list of buttons to press, press the "Configuration" button at the top.
8) Another list of buttons will show and click the "IP Address" button at the top.
9) Now a screen will appear with four boxes. The only two we will worry about currently
are the two on the right, "IP Address:" and "Gateway Address:" See figure 2 for this
screen.
10) Click on the "Gateway Address:" button and enter the gateway address you got from
the network administrator. Note: You may need to click on the first three numbers in
the "Gateway Address:" box to highlight the numbers. Then click on them again to bring
up the menu to start entering the address.
11) Start by typing in the first three digits, the press the next button, do this until the
address has been entered.
12) An example address would be 192.168.1.1. When entering this in, first enter in the 192
and click next, then enter 168 and click next, then enter one and click next, and finally
enter 1 again and click enter. The ending address should like as follows:
192.168.001.001.
Figure 2 – IP Address Menu
IP address box,
make sure this is
unique if more than
one 3500 is on the
same network
Place to enter
default gateway
address received
from network
administrator
