I. SPECIFICATIONS
Model:
Sensor Electronics Corporation SEC 5000 IREvolution Infrared Gas Detector
Available gases:
Methane
Hexafluoro Butadiene
Difluoromethane
Methyl Fluoride
Ammonia
Please note that this list is not all-inclusive. The SEC 5000 IREvolution can be calibrated for many other
gases, provided a calibration gas is available. For more please contact Sensor Electronics Corporation.
Detection Method:
Diffusion
Output (analog):
4-20 mA (Source type), max. 1000 Ohm load at 24 VDC supply voltage
Response Time (Methane Version):
T50 < 15 seconds
T90 < 30 seconds
Construction:
316 stainless steel (SEC 5000)
6061 Aluminum (SEC 5100)
Dimensions: Length x Diameter
Stainless 5.5in x 2.5in
Aluminum 5.75in x 2.75in
Unit Weight:
Stainless Steel 3.7 lb
Aluminum 1.9 lb
Accuracy (Methane Version):
+/- 3% of Full Scale for applied gas concentrations up to 50% of full scale
+/- 5% of Full Scale for applied gas concentrations above 50% of full scale
Operating Temperature Rating:
-40 to +70C at 0 to 99% RH (non-condensing)
Operating Voltage:
24 VDC Operating range: 18 to 32 VDC measured at the detector head
Power Consumption: 5.1 Watts Max.
Max. Current Draw: (at 24 VDC)
Average: 210 mA (Peak: 400 mA)
Approvals: APPROVED MODELS ONLY: 5000/5100
CSA, For -40°C to +50°C operation, Performance Tested C22.2 No. 152
CSA: CI I, Div 1, Grps B,C,D, T5
IECEx ETL 16.0034X: Ex d IIC T5 G
b b
Part Number 1460005
Revision C
