modules this will be empty ||, for Gas detectors this will be the Gas Units (i.e.
5
"ppm" ).
E = DEVICE STATUS: For global or zone status, this will be the number of devices
offline either for the entire bus (global) or the zone (format "OFF 000"), for
relay modules, this will be "OK", "OFFLINE", or "OFFWARN" (for not
responding properly and suspect). For Gas Detectors this can additionally be
"LOWALRM", "MIDALRM", "HIALRM", "FAULT", "MISSING" (for
missing sensor), "INIT" (for sensor or device initialization), "CALIB" (sensor is
being calibrated or user is in the calibration menu), or "SELF TEST" (sensor is
in self test mode
F = LINE STATUS: For global and zone records, this will actually be field E above,
STATUS: with the following contents: "OK", "LOWALRM", "MIDALRM",
"HIALRM", or "FAULT". For Devices, this will be the Mod-Bus Line/Loop
status: "OK" or "LB" for line break detected.
G = LINE STATUS: For global and zone records only ("OK" or "LB", as in field F
above). For devices, this field and pipe symbol will NOT be present.
Examples:
Top Of Loop/Scan Indicator Message:
<Top Of Loop>
Global Status Message:
OK Message
(123 devices configured, 120 online, 3 offline, rollup status OK, line status OK)
<ALL|GLOBAL|CF 0123|ON 0120|OFF 0003|OK|OK>
MID Alarm rollup:
<ALL|GLOBAL|CF 0123|ON 0120|OFF 0003|MIDALRM|OK>
Fault Alarm rollup (higher than HI alarm):
<ALL|GLOBAL|CF 0123|ON 0120|OFF 0003|FAULT|OK>
Zone Status Message:
OK Message
(zone ID #5, 11 devices configured, 7 online, 4 offline, rollup status OK, line status OK)
<05|ZONE|CF 0011|ON 0007|OFF 0004|OK|OK>
High Alarm rollup:
<05|ZONE|CF 0011|ON 0007|OFF 0004|HIALRM|OK>
5
See Note [4] previously.
6
The "SELF TEST" indicator will be inserted before the alarm status: both will be included!
