How to Program

2.1.7 Initial Commissioning

The easiest way of carrying out the initial commissioning is by pressing [Quick Menu] and following the quick set-up
procedure using LCP 102 (read Table 2.3 from left to right). The example applies to open loop applications.
Press
Quick
Menu
Parameter 0-01 Language
Parameter 1-20 Motor Power [kW]
Parameter 1-22 Motor Voltage
Parameter 1-23 Motor Frequency
Parameter 1-24 Motor Current
Parameter 1-25 Motor Nominal Speed
5-12 Terminal 27 Digital Input
Parameter 1-29 Automatic Motor
Adaptation (AMA)
Parameter 3-02 Minimum Reference
Parameter 3-03 Maximum Reference
Parameter 3-41 Ramp 1 Ramp Up
Time
Parameter 3-42 Ramp 1 Ramp Down
Time
3-13 Reference Site
Table 2.3 Quick Set-up Procedure
MG33MJ02
Programming Guide
Q2 Quick Menu
OK Set language
OK Set motor nameplate power
OK Set nameplate voltage
OK Set nameplate frequency
OK Set nameplate current
OK Set nameplate speed in RPM
If terminal default is Coast
inverse, it is possible to change
OK this setting to No function. No
connection to terminal 27 is
then needed for running AMA.
Set desired AMA function.
OK Enable complete AMA is
recommended.
Set the minimum speed of the
OK
motor shaft.
Set the maximum speed of the
OK
motor shaft.
Set the ramping up time with
OK reference to synchronous
motor speed, n
Set the ramping down time
OK with reference to synchronous
motor speed, n
Set the site from where the
OK
reference must work.
