How to Programme
Quick Menus
2 2
Illustration 2.13
Select Q2 Quick Setup to go through a limited amount of
parameters to get the motor running almost optimally. The
default setting for the other parameters considers the
desired control functions and the configuration of signal
inputs/outputs (control terminals).
The parameter selection is effected with the arrow keys.
The parameters in Table 2.2 are accessible.
Parameter
0-01 Language
1-20 Motor Power [kW]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
5-12 Terminal 27 Digital Input
1-29 Automatic Motor Adaptation (AMA)
3-02 Minimum Reference
3-03 Maximum Reference
3-41 Ramp 1 Ramp Up Time
3-42 Ramp 1 Ramp Down Time
3-13 Reference Site
Table 2.2 Selection of Parameter

2.1.7 Initial Commissioning

The easiest way of carrying out the initial commissioning is by pressing [Quick Menu] and following the quick set-up
procedure using LCP 102 (read Table 2.3 from left to right). The example applies to open loop applications.
Press
Quick
Menu
0-01 Language
1-20 Motor Power [kW]
1-22 Motor Voltage
16
0RPM 0.00A 1(1)
Q1 My Personal Menu
Q2 Quick Setup
Q4 Smart Setup
Q5 Changes Made
Setting
[kW]
[V]
[Hz]
[A]
[rpm]
[0] No function*
[1] Enable complete
AMA
[rpm]
[rpm]
[sec]
[sec]
OK
OK
OK
®
VLT AutomationDrive FC 301/302 Programming Guide
* If terminal 27 is set to [0] no function, no connection to
+24 V on terminal 27 is necessary.
Select Changes made to get information about:
•
•
Select Loggings to get information about the display line
read-outs. The information is shown as graphs.
Only display parameters selected in 0-20 Display Line 1.1
Small and 0-24 Display Line 3 Large can be viewed. It is
possible to store up to 120 samples in the memory for
later reference.
Q2 Quick Menu
Set language
Set Motor nameplate power
Set Nameplate voltage
MG33MH02 - Rev. 2013-09-30
the last 10 changes. Use the [
keys to scroll between the last 10 changed
parameters.
the changes made since default setting.
OK
▲ ▼
] [ ] navigation
