Parameters

6.2 Parameter Description

6.2.1 8-0* General Settings
8-01 Control Site
Option: Function:
Select [0] Digital and ctrl.word for using
digital input and control word. Select [1]
Digital only to use digital inputs only. Select
[2] Control word only to use control word
only. This parameter overrules settings in
parameter 8-50 Coasting Select to
parameter 8-56 Preset Reference Select.
[0] Digital and Control by using both digital input and
ctrl.word control word.
*
[1] Digital only Control by using digital inputs only.
[2] Controlword Control by using control word only.
only
8-02 Control Source
Option: Function:
NOTICE
This parameter cannot be adjusted while
the motor is running.
Select the source of the control word.
[0] None
[1] FC Port
*
8-03 Control Timeout Time
Range: Function:
1 s [0.1 - Enter the maximum time expected to pass
*
6500 s] between the reception of 2 consecutive
telegrams. If this time is exceeded, it indicates
that the serial communication has stopped. The
function selected in parameter 8-04 Control
Timeout Function Control Time-out Function is
carried out.
8-04 Control Timeout Function
Option: Function:
Select the timeout function. The time-out function is
activated when the control word fails to be updated
within the time period specified in
parameter 8-03 Control Timeout Time.
[0] Off
*
6.2.2 8-3* FC Port Settings
8-30 Protocol
Option: Function:
Select the protocol for the integrated RS-485
port.
®
VLT DriveMotor FCP 106 & FCM 106 BACnet Operating Instructions
[0] FC
[2] Modbus
[3] Metasys N2
[5] BACNet
1
[0] 2400 Baud
[1] 4800 Baud
[2] 9600 Baud
[3] 19200 Baud
[4] 38400 Baud
[5] 57600 Baud
[6] 76800 Baud
[7] 115200 Baud
[0] Even Parity, 1 Stop Bit
[1] Odd Parity, 1 Stop Bit
[2] No Parity, 1 Stop Bit
[3] No Parity, 2 Stop Bits
0.01 s
MG03O102 - Danfoss A/S © 12/2013. All rights reserved.
8-30 Protocol
Option: Function:
Communication according to the FC Protocol.
Communication according to the Modbus RTU
RTU protocol.
Communication protocol. The N2 software
protocol is designed to accommodate the
unique properties each device may have.
8-31 Address
Range: Function:
[ 0.0 - 247 ] Enter the address for the RS-485 port. Valid
*
range: 1-126 for FC-bus OR 1-247 for Modbus.
8-32 Baud Rate
Option: Function:
Select the baud rate for the RS-485 port
Default refers to the FC Protocol. Changing
Protocol in 8-30 Protocol may change the Baud
Rate.
Changing Protocol in 8-30 Protocol may
change the Baud Rate.
Default setting for
•
Modbus RTU
•
BACnet
•
Metasys N2
8-33 Parity / Stop Bits
Option: Function:
Parity and stop bits for the protocol
using the FC Port. For some of the
protocols, not all options are
available.
Default refers to the FC Protocol.
8-35 Minimum Response Delay
Range: Function:
[ 0.0010 - 0.5 Specify the minimum delay time
*
s] between receiving a request and
transmitting a response. This is used for
6 6
