CDM-750 Advanced High-Speed Trunking Modem
Appendix B
B.2.3.1 OC-3 Single/Multi Mode PIIC Module Summary of Specifications
Item
Interfaces
Data Rate
Framing and Signaling
Direction
Connectors
Fiber
Typical Distance
Output Power
Input Power
Jitter
Diagnostics
Rx Buffer
Description
• OC-3 Single Mode (CEFD Kit KT-0000256)
• OC-3 Multi Mode (CEFD Kit KT-0000257)
155.52 Mbps ±20 ppm
SONET OC-3
SDH STM-1
Full Duplex, allowing Tx/Rx only operation
Duplex LC
• Single Mode: 1300 nm, spectral width 7.7 nm rms
• Multi Mode: 1300 nm, 62.5/125 µm, spectral width 63 nm rms
• Single Mode: Up to 15 Km
• Multi Mode: Up to 500 m
• Single Mode: -12 dBm Typical
• Multi Mode: -14 dBm Typical
• Single Mode: -31 dBm to -8 dBm
• Multi Mode: -35 dBm to -30 dBm
G.825
• Baseband Loopback (at interface)
• Interface Loopback (through interface module)
0.5 to 75 ms in 0.1 ms steps
B–9
Revision 2
MN-CDM750
