9 Communications Functions
Modbus
Register
register
No.
spec. No.
Output relay [AL] on-delay
3798h 3797h
time
Output relay [AL] off-delay
3799h 3798h
time
Logical calculation target 1
37A0h 379Fh
selection of LOG1
Logical calculation target 2
37A1h 37A0h
selection of LOG1
Logical calculation symbol
37A2h 37A1h
selection of LOG1
Logical calculation target 1
37A3h 37A2h
selection of LOG2
Logical calculation target 2
37A4h 37A3h
selection of LOG2
Logical calculation symbol
37A5h 37A4h
selection of LOG2
Logical calculation target 1
37A6h 37A5h
selection of LOG3
Logical calculation target 2
37A7h 37A6h
selection of LOG3
Logical calculation symbol
37A8h 37A7h
selection of LOG3
Logical calculation target 1
37A9h 37A8h
selection of LOG4
Logical calculation target 2
37Aah 37A9h
selection of LOG4
Logical calculation symbol
37Abh 37AAh
selection of LOG4
Logical calculation target 1
37Ach 37ABh
selection of LOG5
Logical calculation target 2
37Adh 37ACh
selection of LOG5
Logical calculation symbol
37Aeh 37ADh
selection of LOG5
Logical calculation target 1
37Afh 37AEh
selection of LOG6
9 - 76
Parameter
Function name
No.
CC-32
CC-33
CC-40
CC-41
CC-42
CC-43
CC-44
CC-45
CC-46
CC-47
CC-48
CC-49
CC-50
CC-51
CC-52
CC-53
CC-54
CC-55
High-function General-purpose Inverter RX2 Series User's Manual
R/W Monitor or setting data
R/W 0 to 10000
R/W 0 to 10000
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
00:AND
R/W 01:OR
02:XOR
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
00:AND
R/W 01:OR
02:XOR
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
00:AND
R/W 01:OR
02:XOR
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
00:AND
R/W 01:OR
02:XOR
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
00:AND
R/W 01:OR
02:XOR
See <List of output terminal func-
R/W tions> 062: LOG1 to 068: LOG7
cannot be selected.
Resolution
0.01(s)
0.01(s)
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
-
