Omron RX2 Series User Manual page 647

Modbus
Register
register
No.
spec. No.
31C4h 31C3h
PID1 Multi stage set-point 15
setting
31C5h 31C4h
Input source selection of
31C6h 31C5h
Set-point 2 for PID1
31C8h 31C7h
Set-point 2 setting for PID1
31C9h 31C8h
Input source selection of
31Cah 31C9h
Set-point 3 for PID1
31CCh 31CBh
Set-point 3 setting for PID1
31CDh 31CCh
Calculation symbol selection
31Ceh 31CDh
of Set-point 1 for PID1
High-function General-purpose Inverter RX2 Series User's Manual
Parameter
Function name
No.
AH-40
(HIGH)
AH-41
(LOW)
AH-42
AH-44
(HIGH)
AH-45
(LOW)
AH-46
AH-48
(HIGH)
AH-49
(LOW)
AH-50
9 Communications Functions
R/W Monitor or setting data
R/W
*4
-100.00 to 100.00
R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
R/W
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
R/W
*4
-100.00 to 100.00
R/W
00: Disabled
01: Ai1 terminal input
02: Ai2 terminal input
03: Ai3 terminal input
04: (Reserved)
05: (Reserved)
06: (Reserved)
R/W
07: Parameter setting
08: RS 485
09: Option 1
10: Option 2
11: Option 3
12: Pulse string input: Inverter
13: Pulse string input: Option
R/W
*4
-100.00 to 100.00
R/W
01: Addition
02: Subtraction
03: Multiplication
R/W
04: Division
05: Minimum deviation
06: Maximum deviation
Resolution
Unit differs
depending
on setting
[AH-03]
[AH-06].
-
Unit differs
depending
on setting
[AH-03]
[AH-06].
-
9
Unit differs
depending
on setting
[AH-03]
[AH-06].
-
9 - 55
