Omron RX2 Series User Manual page 429

 Parameter
Item
PID4 enable
PID4 deviation inverse
Input source selection
of Set-point for PID4
Set-point setting for
PID4
Input source selection
of Process data for
PID4
PID4 proportional gain
PID4 integral time con-
stant
PID4 derivative gain
*1. Data range varies depending on the data from [AJ-44] to [AJ-46].
High-function General-purpose Inverter RX2 Series User's Manual
Parameter Data
00
01
[AJ-41]
02
00
[AJ-42]
01
[AJ-47] 00 to 15
0.00 to
[AJ-50]
*1
100.00(%)
[AJ-52] 00 to 13
[AJ-53] 0.0 to 100.0
[AJ-54] 0.0 to 3600.0(s) Integral gain
0.00 to
[AJ-55]
100.00(s)
Description
Disable
Enable (if command becomes negative, it
does not output in a reverse direction)
Enable (if command becomes negative, it
outputs in a reverse direction)
Disable
Enable (polarity inversion of deviation)
00: Disable, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: Ai4-L input,
05: Ai5-L input, 06: Ai6-L input,
07: Parameter setting [AH-44],
08: RS 485 communication,09: P option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13:Pulse train input (PG Option Unit)
Is a parameter set value.
00: Disable, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: Ai4-L input,
05: Ai5-L input, 06: Ai6-L input,
07: Parameter setting [AH-44],
08: RS 485 communication,09: P option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13:Pulse train input (PG Option Unit)
Proportional gain
Differential gain
8 Applied Settings
Default
data
0
0
07
0
02
1.0
1.0
0.00
8 - 29
