Omron RX2 Series User Manual page 408

8 Applied Settings
 Parameter
Item
PID1 enable
PID1 deviation inverse
PID1 deviation inverse
Set-point-1 setting for
PID1
Input source selection
of Set-point 2 for PID1
Set-point 2 setting for
PID1
Input source selection
of Set-point 3 for PID1
Set-point 3 setting for
PID1
Calculation symbol
selection of Set-point 1
for PID1
*1. Data range varies depending on the data from [AH-04] to [AH-06].
8 - 8
Parameter Data
00 Disable
Enable (if command becomes negative, it does
01
[AH-01] not output in a reverse direction)
Enable (if command becomes negative, it out-
02
puts in a reverse direction)
00 Disable
[AH-02]
01 Enable (polarity inversion of deviation)
00: Disable, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: (Reserved), 05: (Reserved),
06: (Reserved), 07: Parameter setting [AH-10]
[AH-07] 00 to 13 08: RS 485 communication, 09: Option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13: Pulse train input (option)
-100.00 to
[AH-10] This is a set value 1 of PID1 target value 1.
*1
100.00(%)
00: Invalid, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: (Reserved), 05: (Reserved),
06: (Reserved), 07: Parameter setting [AH-44],
[AH-42] 00 to 13 08: RS 485 communication, 09: Option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13: Pulse train input (option)
-100.00 to
[AH-44] This is a set value of PID1 target value 2.
*1
100.00(%)
00: Invalid, 01: Ai1-L input, 02: Ai2-L input,
03: Ai3-L input, 04: (Reserved), 05: (Reserved),
06: (Reserved), 07: Parameter setting [AH-48],
[AH-46] 00 to 13 08: RS 485 communication, 09: Option 1,
10: Option 2, 11: Option 3,
12: Pulse train input (main unit),
13: Pulse train input (option)
-100.00 to
[AH-48] This is a set value of PID1 target value 3.
*1
100.00(%)
01 (Target value 1) + (Target value 2)
02 (Target value 1) - (Target value 2)
03 (Target value 1) x (Target value 2)
04 (Target value 1) / (Target value 2)
[AH-50]
Minimum deviation among input destinations 1,
05
2, and 3
Maximum deviation among input destinations 1,
06
2, and 3
High-function General-purpose Inverter RX2 Series User's Manual
Description
Default
data
00
00
07
0.00
00
0.00
00
0.00
01
