Omron RX2 Series User Manual page 630

9 Communications Functions
Modbus
Register
register
No.
spec. No.
0551h 0550h Retry monitor 9 Factor
Retry monitor 9 Output fre-
0552h 0551h
quency
0553h 0552h (with sign)
Retry monitor 9 Output cur-
0554h 0553h
rent
Retry monitor 9 P-N DC volt-
0555h 0554h
age
0556h 0555h Retry monitor 9 Inverter state
0557h 0556h Retry monitor 9 LAD state
Retry monitor 9 INV control
0558h 0557h
mode
0559h 0558h Retry monitor 9 Limit state
055Ah 0559h Retry monitor 9 Special state
055Ch 055Bh Retry monitor 9 RUN time
055Dh 055Ch
Retry monitor 9 Power ON
055Eh 055Dh
time
055Fh 055Eh
Retry monitor 9 Absolute
0560h 055Fh
time (year, month)
Retry monitor 9 Absolute
0561h 0560h
time (day, day of the week)
Retry monitor 9 Absolute
0562h 0561h
time (hour, minute)
0565h 0564h Retry monitor 10 Factor
Retry monitor 10 Output fre-
0566h 0565h
quency
0567h 0566h (with sign)
Retry monitor 10 Output cur-
0568h 0567h
rent
Retry monitor 10 P-N DC
0569h 0568h
voltage
Retry monitor 10 Inverter
056Ah 0569h
state
056Bh 056Ah Retry monitor 10 LAD state
Retry monitor 10 INV control
056Ch 056Bh
mode
056Dh 056Ch Retry monitor 10 Limit state
Retry monitor 10 Special
056Eh 056Dh
state
0570h 056Fh Retry monitor 10 RUN time
0571h 0570h
Retry monitor 10 Power ON
0572h 0571h
time
0573h 0572h
Retry monitor 10 Absolute
0574h 0573h
time (year, month)
Retry monitor 10 Absolute
0575h 0574h
time (day, day of the week)
Retry monitor 10 Absolute
0576h 0575h
time (hour, minute)
9 - 38
Parameter
Function name
No.
dE-39
dE-40
High-function General-purpose Inverter RX2 Series User's Manual
R/W Monitor or setting data
1 to 255
-59000 to 59000
0 to 65535
0 to 10000
*5
0 to 8
*5
0 to 5
*5
0 to 11
R
*5
0 to 6
*5
0 to 6
0 to 1000000
0 to 1000000
00 to 99 (BCD code)
01 to 12 (BCD code)
01 to 31 (BCD code)
00 to 06 (BCD code)
00 to 23 (BCD code)
00 to 59 (BCD code)
1 to 255
-59000 to 59000
0 to 65535
0 to 10000
*5
0 to 8
*5
0 to 5
*5
0 to 11
R
*5
0 to 6
*5
0 to 6
0 to 1000000
0 to 1000000
00 to 99 (BCD code)
01 to 12 (BCD code)
01 to 31 (BCD code)
00 to 06 (BCD code)
00 to 23 (BCD code)
00 to 59 (BCD code)
Resolution
1
0.01(Hz)
0.01(A)
0.1(Vdc)
1
1
1
1
1
1(hr)
1(hr)
-
-
-
1
0.01(Hz)
0.01(A)
0.1(Vdc)
1
1
1
1
1
1(hr)
1(hr)
-
-
-
