Modbus
Register
register
No.
spec. No.
Speed command destination
27DFh 27DEh
monitor (main)
Speed command destination
28DFh 27DFh
monitor (auxiliary)
Operation command desti-
27E2h 27E1h
nation monitor
Cooling fin temperature
27E7h 27E6h
monitor
27E8h 27E7h Life diagnostic monitor
27ECh 27EBh Total start-up count
27EDh 27ECh Power-on count
27EEh 27EDh
Cumulative operating hours
monitor during RUN
27EFh 27EEh
27F0h 27EFh
Cumulative power-on time
27F1h 27F0h
High-function General-purpose Inverter RX2 Series User's Manual
Parameter
Function name
No.
dC-07
dC-08
dC-10
dC-15
dC-16
dC-20
dC-21
dC-22
(HIGH)
dC-23
(LOW)
dC-24
(HIGH)
dC-25
(LOW)
9 Communications Functions
R/W Monitor or setting data
00: disabled
01: Ai1
02: Ai2
03: Ai3
04: (Reserved)
05: (Reserved)
06: (Reserved)
07: Multistage speed 0
R
08: Sub speed
09: Multistage speed 1
10: Multistage speed 2
11: Multistage speed 3
12: Multistage speed 4
13: Multistage speed 5
14: Multistage speed 6
15: Multistage speed 7
16: Multistage speed 8
17: Multistage speed 9
18: Multistage speed 10
19: Multistage speed 11
20: Multistage speed 12
21: Multistage speed 13
22: Multistage speed 14
23: Multistage speed 15
24: JG
25: RS485
R
26: Option 1
27: Option 2
28: Option 3
29: Pulse array (Inverter)
30: Pulse array (Option)
31: Drive Programming
32: PID
33: (Reserved)
34: AHD retention speed
00: [FW]/[RV] terminal
01: 3 wire
02: RUN key on operator keypad
R 03: RS485 setting
04: Option 1
05: Option 2
06: Option 3
R -200 to 2000
R 0 to 0xFF
R 1 to 65535
R 1 to 65535
R 0 to 1000000
R 0 to 1000000
Resolution
-
-
9
-
0.1(°C)
1
1
1
1(hr)
1(hr)
