Response xx xx xx xx xx xx
In each request frame contents of PZD3 are given by traction until re-select a parameter.
A.2.9 Fault information
EC-TX-103 communication card is equipped with 2 fault display LEDs as shown is figure
below. The roles of these LEDs are as follows:
Fault display LEDs
LED No. Name
2 Online
4 Offline/Fault
A.3 CANopen optional cards
Refer to the operation manual of EC-TX105 CANopen communication cards.
xx xx
Color
ON-module online and data can be exchanged.
Green
OFF-module is not in "online" state.
ON-module offline and data can't be exchanged.
OFF-module is not in "offline" state.
1. Flicker frequency 1Hz-configuration error: The
length of user parameter data sets is different from that
of network configuration process during module
initialization process.
Red 2. Flicker frequency 2Hz-user parameter data error:
The length or content of user parameter data sets is
different from that of network configuration process
during module initialization process.
3. Flicker frequency 4Hz-PROFIBUS communication
ASIC initialization error.
4. OFF-Diagnostic closed.
275
xx xx xx xx 00
Function
Appendix A
00 ... xx xx
